Band saw blade M42 UNIVERSAL

      Universal band saw blade suitable for smaller band saw machines Application: common steels non-ferrous metals structures single and bundle cutting Characteristics: tooth tips made from HSS M42 (DIN 1.3247) variable tooth pitc...

Product code: M42430

Product description

uhel_0     profil_svazek

Universal band saw blade suitable for smaller band saw machines

Application:

  • common steels
  • non-ferrous metals structures
  • single and bundle cutting

Characteristics:

  • tooth tips made from HSS M42 (DIN 1.3247)
  • variable tooth pitch
  • great cutting results and life time expectancy
Dimmensins TPI
mm inch 5/8 6/10 8/12 10/14
6 x 0,90 1/4 x 0,035       V-0
10 x 0,90 3/8 x 0,035       V-0
13 x 0,65 1/2 x 0,025 V-0 V-0 V-0 V-0
20 x 0,90 3/4 x 0,035 V-0 V-0 V-0 V-0
27 x 0,90 1-1/16 x 0,035 V-0 V-0 V-0 V-0
34 x 1,10 1-3/8 x 0,042 V-0 V-0 V-0 V-0
41 x 1,30 1-5/8 x 0,050 V-0 V-0

V-O = variable tooth pitch and zero rake angle

Please don´t forget proper break-in of band saw blades, you achieve significantly better cutting results and band life time expectancy. Set for first 20 minutes feed rate to 50% and cutting speed to  80% of normal values.



Komentáře

Tento produkt nebyl ještě hodnocen.

Komentář

Parametry

Band choice 10x0,90 10/14z; 13x0,65 5/8z; 13x0,65 6/10z; 13x0,65 8/12z; 13x0,65 10/14z; 20x0,90 5/8z; 20x0,90 6/10z; 20x0,90 8/12z; 20x0,90 10/14z; 27x0,90 5/8z; 27x0,90 6/10z; 27x0,90 8/12z; 27x0,90 10/14z; 34x1,10 5/8z; 34x1,10 6/10z; 34x1,10 8/12z; 34x1,10 10/14z; 41x1,30 5/8z; 41x1,30 6/10z;
Width 10; 13; 20; 27; 34; 41;
Thickness 0,90; 1,10; 1,30;
TPI 6/10; 8/12; 10/14;
